Rotel screens are electroformed with pure nickel. Its technical qualities require substantial know - how coupled with uncompromising precision at all stages. Every single screen is subjected to rigorous in - process quality control. ROTEL Rotery Screens are suitable for use on all rotery screen printing machines irrespective of whether they operate with metal or rubber squeeze.
This screens are available in a wide variety of repeat size and length, as well as mesh counts. ROTEL Screens have greater stability which leads to easier handling with less risk, increasing the serviceable life of the screen.
Each ROTEL Screen is uniform and faultless with exact repeats. With their execellent ductility the chances of their cracking (particulary at high squeegee tension) are significantly reduced. Thanks to their specially developed surface texture, ROTEL screens provide good adhesion for all known coating emulsions and because the relationship between the apertures and the webs separating them is ideal, these screens have what it takes to produce flaweless printing results with all types of dyes and textiles.
ROTEL® 80 ED
Extra thick, Extra durable 80 ED mesh screens have technical specification of thickness 100 microns and 14% O.A. making them highly economical, due to lower screens wear at higher printing speeds even with highly corrosive printing pastes.
ROTEL® 100 ED
Our of the complete range of Rotel ED Screens, the new 100 ED screens are having higher thickness (about 105 microns) against that of conventional 100 mesh (about 95 microns) with higher open area (about 14 %)against that of standard(about 8%), give these screens an extra edge, making surface, outline and detail printing down to 0.20 mm easy even at higher operating speeds with minimum of breakage while printing. 100 ED with above technical specifications boasts to be the only screen of its kind in the market today.
Apart from these quality printing benefits. Rotel ED screens are found economical as they give greater durability due to higher thickness.
| REPEAT | 640 | 640 | 640 | 640 | 640 | 640 | 640 | 640 |
|---|---|---|---|---|---|---|---|---|
| MESH | 40 | 40 ED | 60 ED | 70 ED | 80 | 80 ED | 100 | 100 ED |
| PKG | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
ROTEL® EDX
Rotel EDX screen's build on all the leading strengths of
Rotel ED plus much more...
1. Increased Screen Wall Thickness
2. Larger Open Area than ED screen's
These screen's have been specially developed by Gurjar
R&D team keeping in mind the needs of our African
printers printing khanga and ketange fabrics for solid
blotches and both side mirror effect printing.
Due to these additional properties make Rotel EDX very durable and multitimes strippable screen's compared to any other make screen's in the marketplace.
Our entire production of Rotary screen is subject to an individual inspection i.e.
- Perforation
- Thickness
- Ductility
- Open Area
ROTEL EDX
| REPEAT | MESH | PKG |
|---|---|---|
| 640 | 60 EDX | 20 |
| 640 | 70 EDX | 20 |
| 640 | 80 EDX | 20 |
| 640 | 100 EDX | 20 |
ROTEL® LRL2
The new LRL2 screens are made available in all ROTEL type mesh counts having higher thickness coupled with higher open area (O.A. %). The unique combination of higher thickness with higher open area than standard ROTEL and DELTA type screens with extra remarkable tensile properties of LRL2 now enables the rotary screen printer to obtain perfact reproduction of all types of prints on all textile materials with a very high tolerance factor and a longer service ability of the screens.
Distinct Advantages of ROTEL LRL2 (LONG RUN LONG LIFE) screens over other standard screens.
- Higher Thickness coupled with higher ductility impart substantial Long Life over Long Print Run making them highly economical screens than standard screens.
- Adequate Open Area with corresponding higher thickness than standard screen, impart superier performance in terms of better colour penetration, hence giving better printing ability for printing large blotches.
- Easily strippable after polymerisation and printing.
- Pinning and Retouching made easy due to adequate open area and hole diameter of the mesh.
- Much lesser choke - up problems (no clogging) even while printing with thicker printing paste.
